FRIULINOX AG 48

MAIN FEATURES
External panels in stainless steel (Scotch-Brite satin-finish)
Outside back and external bottom in zinc-plated steel
Inner in stainless steel with rounded corners
Cavity with central drain for discharge of washing water
Insulation in high density (42 kg/m3 approx.) expanded
polyurethane, 60 mm thick, HCFC-free
Copper-aluminum evaporator with cataphoresis anti-corrosion
treatment
Painted iron condensing coil with high thermal output
Heating element in the door frame
Door in stainless steel (Scotch-Brite satin finish)
Self-closing door with block in open position at 100°
Built-in door handle and magnetic gaskets on all 4 sides of the
door
Stainless steel feet Ø 2”height-adjustable H 150÷180mm with
anti-scratch cap
INTERNAL SETUP:
5 stainless steel shelves on adjustable slides and uprights
Possibility of using 2 pitches for positioning guides (35-50 mm)
COOLING SYSTEM:
System mounted on a single block structure with steps, which
enables optimal use of internal space
Evaporator with high-power fan to ensure maximum cooling
system efficiency
Monoblock chiller unit removable from above for simple and
easy servicing and replacement
R404A refrigerant
Automatic electric defrosting
Automatic defrosting device and evaporation system of water
condensation without electrical energy
CONTROLS AND SAFETY DEVICES:
DIGITAL TELETHERMOSTAT with 2 NTC type sensors (cell
and defrosting-end)
Timer press-buton for continuous cold function (max. 6 hours)
Switching from a continuous cycle to a thermostatically
controlled cycle
Intelligent defrosting with the insertion of an electrical heater,
only in case of freezing evaporator
Compressor protected by termic overload cut-out with
automatic reset
Micro-switch stops internal fan when door is open
Door lock and key
